BOE 15.6 Inch PC LCD Module TFT-LCD Display Panel with 2560x1440 Pixels 300cd/m2 Brightness and 165Hz Frame Rate for Laptop and Gaming

Brand Name : BOE

Model Number : NE156QHM-NY4

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W,Western Union,MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

material : glass

Brightness : 300ccd/m2

Resolution : 2560*1440pixels

contrast ratio : 1200:1

color : 1.07B

Working life : 15k hours

connector : 40P

Touch panel : without

Contact Now

BOE 15.6-Inch PC LCD Module NE156QHM-NY4
High-resolution 2560*1440 Quad-HD display panel with 188 PPI and 300 cd/m² brightness, designed for laptops and gaming applications.
Product Overview
The BOE NE156QHM-NY4 is a 15.6-inch diagonal Oxide TFT-LCD display panel featuring an integrated WLED backlight system with LED driver. This panel does not include a touch screen and is engineered for demanding applications requiring high performance and reliability.
Key Features
  • 165Hz refresh rate for smooth gaming and video
  • 10-bit color depth supporting 1.07 billion colors
  • 100% sRGB color gamut for accurate color reproduction
  • eDP 1.4 interface with 4 lanes
  • Matte finish with anti-glare hard coating (3H)
  • LED DC dimming, PSR, OD, DDS, BIST, and FRC technologies
BOE 15.6 Inch PC LCD Module TFT-LCD Display Panel with 2560x1440 Pixels 300cd/m2 Brightness and 165Hz Frame Rate for Laptop and Gaming
Technical Specifications
BrandBOE
Model P/NNE156QHM-NY4
Diagonal Size15.6"
Panel TypeOxide TFT-LCD, LCM
Resolution2560(RGB)*1440 (Quad-HD), 188 PPI
Pixel FormatRGB Vertical Stripe
Active Area344.22(W)*193.62(H) mm
Outline Dimensions350.66(H)*214.72(V)*2.6(D) mm
Surface TreatmentAntiglare, Hard coating (3H)
Luminance300 cd/m² (Typical)
Contrast Ratio1200:1 (Typical)
Viewing Angle85/85/85/85 (CR≥10)
Response Time9ms (Typical, Tr+Td)
Operating ModeADS, Normally Black, Transmissive
Color Support1.07 billion colors, 100% sRGB
Light SourceWLED [11S5P], 15K hours, With LED Driver
Frame Rate165Hz
Touch PanelWithout
Interface TypeeDP (4 Lanes), eDP1.4, HBR3 (8.1G/lane), 40-pin Connector
Power Supply3.3V (Typical)
Form StyleSlim (PCBA Flat, T≤3.2mm)
Environmental Specifications
Operating Temperature0°C to 50°C
Storage Temperature-20°C to 60°C
Max Vibration Level1.5G (14.7 m/s²)
Application Recommendations
This display panel is specifically designed for laptop computers and gaming applications where high resolution, fast refresh rates, and accurate color reproduction are essential.
Mass production began in Q2 2021. For the latest production status and detailed specifications, we strongly recommend contacting BOE or its authorized distributors directly. The information provided is for reference only and should not be used as the sole basis for decision-making.
